This list has not been updated yet. If you need a schematic by this manufacturer, please email for availability.

500 schematic

Tube amp: 12AU6, 12AV6, 50L6, 35Z5 4 inputs, Volume and Tone controls on each channel, tremolo 8 ohm spkr AC/DC amp (no power transformer)
$5.00
 Buy Now

503-A schematic

Tube amp: 12AU6, 50L6, 35Z5 4 inputs, Volume and Tone controls Single spkr AC/DC amp (no power transformer)
$5.00
 Buy Now

506 schematic

Tube amp: 12AU7, 12AX7, (2) 6V6, 5Y3 4 inputs (2 on each channel), Volume control on each channel, master Tone control, tremolo 8 ohm spkr
$5.00
 Buy Now

515 schematic

Tube amp: (3) 12AX7, (2) 6V6, 5Y3 4 inputs (2 on each channel), Volume and Tone controls on each channel, tremolo 1 spkr
$5.00
 Buy Now

540 schematic

Tube amp: 20EZ7, 60FX5, 36AM3 Reverb converter Single spkr AC/DC amp (no power transformer)
$5.00
 Buy Now

610 schematic

Tube amp: (2) 6EU7, 5879, 7199, 6AU6, (2) 7027, 5U4 6 inputs (3 on each channel), Volume, Bass, and Treble controls, tremolo 4 spkrs
$5.00
 Buy Now

700 schematic

Solid-state amp 3 inputs (Bass, Normal, Treble), Volume and Tone controls 8" spkr
$5.00
 Buy Now

703 schematic

Tube amp: 12AU6, 50L6, 35Z5 3 inputs, Volume and Tone controls Single spkr AC/DC amplifier (no power transformer)
$5.00
 Buy Now

703-C schematic

Tube amp: 18GD6A, 60FX5, 36AM3 3 inputs, Volume and Tone controls Single 8 ohm spkr AC/DC amp (no power transformer)
$5.00
 Buy Now

704 (Second version) schematic

Solid-state amp (7 transistors) 3 inputs, Volume and Tone controls, tremolo 8 ohm spkr
$5.00
 Buy Now
